M3-7-U
Call Us : +86-20-86050667
|
Carkuda Home > Carkuda
M3-7-U
  • M3-7-U
  • M3-7-U
  • M3-7-U

M3-7-U

INQUIRY
5 Inch Carkuda for special device

1.Carkuda Mirror is installed in vehicles
2.Carkuda hardware connect to battery, ACC power
line,  signal line,GPS antenna
3.With data network, mirror talks to Services Cloud
4.Data network can be combination of
2G/3G/4G/Wi-Fi
5.Services cloud can be public known like Google
Map, or manufacturer provided cloud
6.User can user Carkuda Mirror directly by touch screen
7.Smartphone connect to Mirror by data network
8.Smartphone access mirror data from Service Cloud

Specification

Type Item Note

Radio Network
WCDMA 2100Mhz, UMTS/HSPA/HSPA+
GSM 850/900/1900/1800Mhz,GSM/EDGE


Wireless connection
GPS Support GPS(Standalone and A-GPS)
Bluetooth 4.0, not for hand free.accessories only
Wi-Fi 802.11b/g/n; @2.4GHz;
WEP/WPA/WPA2,Access Point for Tethering, 72.2Mbps or less
Interfaces Antennas GPS,WI-FI/BT, FM,3G
Power 12V, has over Voltage protection
SIM/USIM Micro-SIM
LCD 5 inches,IPS touch screen 480*854
Camera Front facing camera,at 720P or 1080P seletable by user
MIC Support
ACC detection Support
Micro-SD Card Support Micro-SD,Maximum 32GB
Sensors G-sensors Collision detect
Radar Not support
Software OS Base Android 4.4
FM transmitter Support
Media Playback Support
Rear camera Support  for rear video
Smartphone Support App Data Synchronization
Physicals Sizemm 286.5*90*46.48mm
Languages English, Chinese, Russian, Janpanese
System Memory 1GB DDR3+8GB/16GB eMMC
Chipsets MTK 8312CW
Working temperatures -20-70℃
Humidity 95%RHat 45℃
